最新的 Autodesk Certified Professional RVT_ELEC_01101 免費考試真題 (Q33-Q38):

問題 #33
Refer to exhibits.

An electrical designer models an existing receptacle on an existing wall that the architect has indicated to be demolished.

The view is intended to show demolition, and the view's Phase is set to New Construction. How should the designer indicate that the receptacle must also be demolished?

答案：B

解題說明：
In Autodesk Revit, phasing allows designers to track existing, demolished, and new elements across different project stages. Every model element includes two key phasing parameters:
Phase Created - defines when the element was built or introduced.
Phase Demolished - defines when the element is removed or demolished.
In the provided exhibits:
The project contains two phases: Existing and New Construction.
The receptacle's Phase Created parameter is set to Existing, indicating it belongs to the pre-existing building condition.
The architectural wall hosting the receptacle is to be demolished during New Construction.
When a view's Phase is set to New Construction and its Phase Filter is configured to show demolition, only elements whose Phase Demolished equals New Construction will appear as to be demolished. Therefore, the electrical designer must set the receptacle's Phase Demolished value to New Construction so that it graphically displays as a demolished element in the demolition plan.
As explained in the Autodesk Revit MEP User's Guide - Phasing and Coordination:
"Elements created in one phase and demolished in a subsequent phase must have their 'Phase Demolished' parameter set to that later phase to display properly in demolition views." Thus, to correctly coordinate with the demolition of its host wall, the receptacle must be flagged for demolition during New Construction.


問題 #34
Refer to exhibit.

An electrical designer tries to place a generic annotation family in a data device family. The designer receives the error message as shown. What should the designer do?

答案：D

解題說明：
The warning message - "Can't create this kind of element in this view in the current mode" - appears when an electrical designer attempts to place a Generic Annotation family inside a model family (e.g., a data device or electrical fixture) that is not configured to host annotation elements.
According to the Revit Electrical Design documentation, Generic Annotation families are 2D annotation elements, and therefore, cannot be created or viewed in 3D model views unless configured as "Shared." The official guide clarifies:
"You can create generic annotation families and nest them inside host model families so that the annotations display in the project." However, this only functions correctly if the annotation is enabled to act independently within the host:
"To allow a nested annotation to be visible and editable when placed in a host model family, the nested annotation must be set to Shared before loading it into the host." If the nested annotation is not set to Shared, Revit cannot create or display it in the host's model view, triggering this exact warning.
Thus, the correct workflow is:
Open the Generic Annotation family in the Family Editor.
Go to Family Category and Parameters.
Check the box "Shared" under Family Parameters.
Save and reload the family into the host electrical device family.
Other options-changing view level, detail level, or annotation orientation-do not resolve this placement restriction.


問題 #35
What should an electrical designer do to associate a lighting device with light fixtures in a model?

答案：D

解題說明：
In Autodesk Revit Electrical Design, a lighting device (switch) must be associated with lighting fixtures through a switch system, not through electrical circuits. Switch systems are independent of lighting circuits and wiring, as they are intended to represent the control relationship between a light switch and the lighting fixtures it operates.
According to the Autodesk Revit MEP User's Guide (Chapter 17 - Electrical Systems, pages 475-478), the official method is described under "Creating a Switch System."
"You can assign lighting fixtures to specific switches in a project.
The switch system is independent of lighting circuits and wiring."
(Revit MEP User's Guide, p. 475)
"To create a switch system:
Select one or more lighting fixtures in a view, and click
Modify | Lighting Fixtures tab ➤ Create Systems panel ➤ Switch.
Click Switch Systems tab ➤ System Tools panel ➤ Edit Switch System.
Click Add to System, and select one or more lighting fixtures.
Click Select Switch, and select a switch in the drawing area.
Click Finish Editing System."**
(Revit MEP User's Guide, p. 476)
How It Works:
The switch system links a lighting device (switch) with lighting fixtures, enabling Revit to manage how light fixtures respond to specific switches.
Unlike electrical circuits, which define power flow and load connections to panels, the switch system defines control logic (which lights are turned on/off by which switch).
The designer begins by selecting the switch and then adding lights to its system, ensuring all lights associated with that switch are grouped correctly.
Supporting Extract from Revit Documentation:
"You can also create a lighting switch system by right-clicking the connector for a lighting fixture and clicking Create Switch System." (Revit MEP User's Guide, p. 475)
"Add lighting fixtures to the switch system...
Click Select Switch and select a switch in the drawing area."
(Revit MEP User's Guide, p. 476)
"The switch system is independent of lighting circuits and wiring."
(Revit MEP User's Guide, p. 475)
Conclusion:
To associate a lighting device (switch) with light fixtures in a Revit electrical model, the designer must create a switch system. This is done by selecting the switch, then adding the desired lighting fixtures to that system using the Add to System and Select Switch tools under the Switch Systems tab.


問題 #36
An electrical designer is creating an electrical fixture family for a receptacle. The designer nests a generic annotation family that contains the receptacle symbol and a label What must be done in the electrical fixture family so that the label value can be changed in a project?

答案：D

解題說明：
In Revit, when a designer nests a Generic Annotation family (such as a receptacle symbol) inside an Electrical Fixture family, and that annotation includes a label, the label value cannot be changed directly in the project unless the parameter controlling that label is properly associated (linked) to a parameter in the host (electrical fixture) family.
According to Autodesk Revit Electrical Design documentation, under "Creating Family Parameter Links", it is explicitly stated:
"By linking family parameters, you can control the parameters of families nested inside host families from within a project view. You can control instance parameters or type parameters." The procedure describes the correct process to make the label value editable in a project:
"Click the button next to a parameter that is of the same type as the one you created in Step 6. For example, if you created a text parameter, you must select a text parameter here. In the dialog that displays, select the parameter you created in Step 6 to associate it with the current parameter, and click OK."
"The nested family changes according to the value you entered."
This means that the designer must associate the nested family's label parameter (usually a text parameter controlling the annotation label) to a corresponding parameter in the host electrical fixture family. Once linked, this host parameter appears in the project's Properties palette, allowing the designer to change the label value directly.
Other options-such as creating formulas, modifying visibility, or enabling "Shared"-do not make the label editable in the project unless the parameter link is established.


問題 #37
Refer to exhibit.

To which panel Is Panel P4 circuited?

答案：C

解題說明：
In Autodesk Revit MEP Electrical Design, the System Browser is used to analyze and verify electrical systems, including panelboard connections, circuit hierarchies, and connected loads.
From the exhibit, the Properties palette shows that the selected equipment is a Lighting and Appliance Panelboard (208V MLO, 100A), named P4. To determine the parent panel that feeds Panel P4, we refer to the System Browser, which organizes the entire electrical distribution network hierarchically under the Electrical discipline.
In the System Browser on the right, under the Electrical category, we can observe that Panel P4 is nested directly under Panel P2. This organization indicates that P4 is circuited to (or fed from) Panel P2.
According to the Revit MEP 2011 User's Guide, Chapter 4, "Electrical Systems-Using the System Browser," it states:
"The System Browser displays electrical systems in a tree structure. Each subpanel or device listed beneath a main panel is connected to that panel through an electrical circuit. When a panelboard appears under another, it indicates the subpanel is fed from that parent panel." This is further reinforced in Smithsonian Facilities Revit Electrical Template Documentation (April 2021), Section 8.3 "Documentation Views," which describes:
"Panel schedules and browser hierarchies show the distribution sequence. Subpanels appear indented beneath their source panel, indicating electrical dependency and circuit assignment." Therefore, by interpreting both the Revit interface and Autodesk's documentation, Panel P4 is a subpanel connected to Panel P2, confirming that its electrical feed is assigned from Panel P2.
Final Verified answer: B. Panel P2
Reference Sources:
Autodesk Revit MEP 2011 User's Guide, Chapter 4 - Electrical Systems and the System Browser Smithsonian Facilities Revit Template User's Guide, Section 8.3 - Electrical and Fire Alarm Templates: Documentation Views


問題 #38
......
